2016 AllSlotCar Formula GP Series

2016formulagpSeries Manager: Mark; Ass. Manager: Steve.
This series will be raced in the second quarter of 2016 (Q2).

Final Rule-set

Fees

Entrance fee per race is $5 for ASCC members, and $10 for non-members.

Models Allowed

Any 1/32 AllSlotCar Formula GP cars.

Body

  • White kits must be painted and racing number must be added.
  • Minimum body weight is 9 grams.
  • Camera pod and side mirrors can be removed.
  • Front spoiler and rear wing must be attached at all times. Rear wing attachment can be reinforced with glue or tape (inside of the wing –  no tape is allowed on the top surface of the wing).

Chassis

  • SVQ-Slot Fórmula 1 MIXTO: part# SVQ-CH132-F1-CA.
  • Light sanding of the frame is allowed in areas that meet with the body is allowed. No other alterations are permitted.

Motor Mount, Suspension and Bushings

  • Slot.it Inline Boxer non-offset motor-pod only, part # CH48.
  • The motor pod needs to be modified in order to fit in the chassis. Allowed modifications are (use the following image as guide):
    • Removal of crown gear protecting arch.
    • Removal of rear side support.

motor-pod-modification

Gear, Axles, Pick-up Guides and Fasteners

  • Open choice.
  • Axle spacers and stop collars are allowed and free choice.

Wheels and Tires

  • Any variation of AllSlotCar front wheels (ASGP007 or ASGP056) and rear wheels (ASGP008 or ASGP055) may be used. Air ride system may be filled with o-rings or other suitable material.
  • Original wheel insert must be installed.
  • Front tires: Stock (ASGP009).
  • Rear tires: NSR F1 Supergrip Tires (p/n 5220).
  • Minimum tire diameter before race is 18mm.

Motor

  • Stock motor (AS001).
  • Motor shaft may be reduced to accommodate crown gear.

Weight

  • Maximum car weight is 100 grams.
  • Ballasts are free choice.

Measurements

  • Group A: Maximum track (Front/Rear) is 64mm.
  • Group B: Maximum track (Front/Rear) is 66mm.

Track Power

The series will be raced at 12 Volts.

General

If it is not mentioned it is not legal. These rules were written to create a fair event and not for racers to look for loopholes.
